Product Introduction
This product is based on the NB IoT communication network and GPS+Beidou satellite positioning system. It can locate or monitor remote targets through the internet, using the most advanced GPS+Beidou and LBS dual positioning technology. The NB IoT communication method has the advantages of low power consumption and good signal penetration. The product is designed according to a universal wide voltage vehicle product, without the need for an external transformer. It can be directly used in various models such as electric vehicles, motorcycles, logistics vehicles, private cars, etc. The product has a flexible and simple appearance, and is easy to install and convenient.
Product advantages
| NB IoT+GPS+Beidou+Acceleration+Gyroscope | Ultra wide operating voltage range |
| low-power consumption | Unique exterior design |
| Protocol compatible with third parties | Support for mobile apps |
| Customer customization |
Product specifications
|
size |
72 (L)*35(W)*17(H)mm |
GPS sensitivity |
-162dBm |
|
Support voltage |
Ultra wide voltage input: DC 8-100V |
positioning accuracy |
5m |
|
Backup battery |
110mAh/3.7V |
gps antenna |
25mm X25mm X4mm ceramic antenna |
|
Standby current |
0.5mA |
sensor |
Built in 3D acceleration sensor, 3D gyroscope, and temperature sensor |
|
support network |
NB-IoT 3GPP R13/R14 |
LED indicator light |
Power/NB IoT network/GPS |
|
Support frequency band |
B1,B3,B5,B8,B20,B28 |
operation temperature |
-20 ° C to+85 ° C |
|
SIM card |
Equipped with built-in high reliability patch SIM, capable of supporting e-SIM |
humidity | 5% to 95% non condensing |
|
locate mode |
GPS、北斗、GLONASS、LBS |
