Product Introduction

CFB-609B is a highly integrated module that supports NB IoT standard communication. NB IoT supports the full frequency range of 698-2180MHz and Band 1, 3, 5, 8, and 20. Supports E-SIM function. It is mainly used for low-power data transmission services and complies with NB IoT
Radio communication protocol (3GPP Release-13/14/15) standard.
The CFB-609B module can be connected to numerous terminal devices, embedded with data transmission protocols such as TCP/UDP/CoAP/MQTT/DTLS/DTLS+, and supports 3GPP Rel13/14/15 and extended AT commands. Support base station positioning. It can almost meet the application needs of all IoT applications. For example, intelligent measurement, shared bicycles, intelligent parking, smart cities, security, asset tracking, smart appliances, agriculture and environmental monitoring, etc.
CFB-609B supports secondary development and has 19 GPIOs, which can support SPIx1, UARTx3, I2Cx2, ADCx2, and PWMx1 standard interfaces.
CFB-609B is packaged with LCC patches and has a 20mm thickness × 16mm × A super small size of 2.2mm.
The CFB-609B module adopts power-saving technology, with a power consumption of approximately 1uA in power-saving mode (PSM).

Product advantages

Ultra low power consumption, ultra

high sensitivity

Embedded rich network service protocol stack

Compact NB IoT wireless communication

module

LCC chip packaging, suitable for mass production

The packaging design is compatible with Yuncheng Technology CFB-801 module,

making it easy to upgrade products

By providing reference designs, evaluation boards, and timely technical support, customers' requirements for rapid

product launch can be met

Product specifications

power supply	VBAT power supply voltage range: 2.1V-4.2V Typical power supply voltage: 3.6V
Power	Maximum current consumption under PSM: 1uA
Frequency band	Band 1、3、5、8、20
Transmitting power	23dBm±2dB
temperature range	Normal working temperature: -35 ° C~+75 ° C * 1 Extended working temperature: -40 ° C~-+85 ° C * 2
USIM card interface	Support for USIM card: 1.8V/3V
Antenna interface characteristic impedance	50 Ω
Serial port	Main serial port: AT command transmission or data transmission, with a baud rate of 115200bps, Upgrade serial port: Software upgrade with a baud rate of 115200bps
Physical Characteristics	Dimensions: length 20 ± 0.2 mm, width 16 ± 0.2 mm, thickness 2.2 ± 0.2 mm Weight: 1.6g
UPGRADE	Debug UART
